Brand Name : | OEM |
Model Number : | ORCB007 |
Certification : | ISO9001 |
Price : | Negotiation |
Payment Terms : | T/T, Western Union, L/C |
Delivery Time : | 3-7 work days |
Fiber Count | Cable Dimension(mm) | Cable Weight(kg/km) | Tensile(N) | Crush(N/100mm) | Min Bend. Radius(mm) | Range of Temperature(℃) | |||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | ||||
1 | 2.5 | 6 | 100 | 200 | 200 | 1000 | 60 | 30 | -20-+70 |
1 | 3.0 | 7.5 | 200 | 400 | 200 | 1000 | 60 | 30 | -20-+70 |
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable core use the colored coating fiber of 250μm; 3. The tensile and crush of the cable are accordance with the values in the table when the strength member of FRP and Steel are used; 4. The minimum bend radius(static) is 15mm when G.657 fiber is used. |
Product Advantages
![]() |
