Brand Name : | OEM |
Model Number : | ORCA014 |
Certification : | ISO9001 |
Price : | Negotiation |
Payment Terms : | T/T, Western Union, L/C |
Delivery Time : | 3-7 work days |
Fiber Count | Cable Dimension(mm) | Cable Weight(kg/km) | Tensile(N) | Crush(N/100mm) | Min Bend Radius (mm) | Min Bend Radius (mm) | Range of Temperature(℃) | ||
Long Term | Short Term | Long Term | Short Term | Dynamic | Static | ||||
2 | 2.5X3.5 | 7.3 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
4 | 2.5X3.5 | 7.4 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
6 | 2.5X4.0 | 8.2 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
8 | 2.5X4.5 | 9.3 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
12 | 2.5X5.0 | 10.0 | 80 | 200 | 200 | 500 | 50 | 30 | -20-+60 |
Note: 1. All the values in the table, which are for reference only, are subject to change without notice; 2. The cable dimension in the table, which are according to single ribbon, are subject to change with ribbon count; 3. The minimum bend radius(static) is 15mm when G.657 fiber is used. |
Product Advantages
![]() |
