Brand Name : | OEM |
Model Number : | FC/APC-FC/APC-1F-3.0-0.5M |
Certification : | ISO9001 |
Price : | Negotiation |
Payment Terms : | T/T, Western Union, L/C |
Supply Ability : | 1000,000 connectors/month |
Delivery Time : | 3-7 work days |
Items | Single mode | Multimode | ||||||
PC | UPC | APC | 62.5/125 | 50/125 | 50/125 10G | |||
Insertion Loss | <0.3dB | <0.2dB | ||||||
Return Loss | ≥45dB | ≥50dB | ≥60dB | ≥35dB | ||||
Durability | <0.1dB typical change, 500 matings | |||||||
Operating Temperature | -40 to +75 | -40 to +75 | ||||||
Ferrule Hole Sizes | 125.0+1/-0um, Conentricity:≤1um | 125um,Conectricity:1≤3um | ||||||
125.3+1/-0um, Conentricity:≤1um | 127um,Conectricity:1≤3um | |||||||
125.5+1/-0um, Conentricity:≤1um | 128um,Conectricity:1≤3um | |||||||
126.0+1/-0um, Conentricity:≤1um |
- Plug-in fasten structure and stable connection
- Protected by spring-loaded shutters
- High quality ferrule
- Various cable diameters available:Φ0.9, Φ2.0, Φ3.0mm
- PC(SPC/UPC), APC polishing available
- Comply with ICE standards,
- RoHS compliant
- Telecommunication
- Computer networks
- CATV networks
- Active device termination
- Instrumentation
Ordering information
1) Connector type: FC, SC, LC, ST, LSH(E2000), MU, MTRJ
2) Ferrule End-face: PC, UPC, APC
3) Gender: male, female
4) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or
62.5/125um)
5) Cable Quantity: simplex, duplex
6) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
7) Cable Length: 1, 2, 3 meter or customized
8) Cable type: PVC, LSZH, OFNR, OFNP
![]() |
