    9/125um UPC polishing Fiber Optic Patch Cable Single Mode SC To SC

    Ask Lasest Price
    Brand Name : OEM
    Model Number : SC/UPC-SC/UPC-2F-SM-2.0-L-5M
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 1000,000 connectors/month
    Delivery Time : 3-7 work days
    • Product Details
    • Company Profile

    9/125um UPC polishing Fiber Optic Patch Cable Single Mode SC To SC

    9/125um UPC Polishing Fiber Optic Patch Cable Single Mode SC To SC


    9/125um fiber optic patch cables single mode SC to SC


    Definition of 9/125μm DX Patch cord


    This fiber optic cable with customized length is terminated with SC connectors on both ends. It is a singlemode fiber (9 micron core) designed to transmit data across long distances at high speeds. The cord is duplex (two fibers) which means it permits synchronous communication between devices. The cladding diameter is 125 microns.


    Fiber optical patchcord parameters


    Characteristics

    Unit

    Value/Performance


    Comments



    SM

    MM




    APC

    PC



    Basic

    Insertion Loss(IL)

    dB

    ≤0.3

    IEC61300-3-4

    Insertion Loss(RL)

    dB

    SPC≥45

    UPC≥50

    ≥60

    ≥23

    IEC61300-3-6

    Endurance

    dB

    △IL≤0.2

    IEC61300-2-2

    Operation Temperature

    -20 to +70


    Speration Temperature

    -40 to +70


    Ferrule end-face geometry

    Radius of curvature(R)

    mm

    7-25

    5-12

    NA

    Telcordia GR326(4.4.5)

    Apex offset

    um

    ≤50

    NA

    Telcordia GR326(4.4.5)

    Fiber protrusion

    nm

    ≤50

    ≤100

    NA

    Telcordia GR326(4.4.5)

    Fiber under cut

    nm

    ≤125@R=7-10

    ≤100

    NA

    Telcordia GR326(4.4.5). For PC, under cut≤-0.02R³+1.3R²-31R+325 when R=10-25mm

    Mechanical






    Drop

    dB

    △IL≤0.2

    IEC61300-2-12, 1.5m, 5 drops, no damage

    Vibration

    dB

    △IL≤0.2

    IEC61300-2-1, 10-55Hz, 0.75mm amplitude, 0.5hrs/axis

    Flex

    dB

    △IL≤0.2

    Telcordia GR326(4.4.3.2), 0.6kg, ±90°, 100cycles, for 2mm or larger cable

    Twist

    dB

    △IL≤0.2

    Telcordia GR326(4.4.3.3), 1.35kg load, ±2.5 turns, 10cycles, for 2mm or larger cable

    Pull proof

    dB

    △IL≤0.2

    Telcordia GR326(4.4.3.4), 2.3kg at 90°, 6.8kg at 0°, for 2mm or larger cable

    Coupling strength

    dB

    △IL≤0.2

    IEC61300-2-6, 4.2kg, 2min

    Static bending

    dB

    △IL≤0.2

    IEC794-1-2, 60mm diameter 10 turns

    Crushing

    dB

    △IL≤0.2

    IEC794-1-2, 102kg for 2mm or larger cable, 10.2kg for 900um cable

    Environmental




    Cold

    dB

    △IL≤0.2

    IEC61300-2-17, -20℃, 96 hrs

    Dry heat

    dB

    △IL≤0.2

    IEC61300-2-18, 70℃, 96 hrs

    Damp heat

    dB

    △IL≤0.2

    IEC61300-2-19, 40℃, 95% RH, 96 hrs

    Transmission




    Characteristics

    Unit

    G652 SM

    G655 SM

    Std. 50um

    62.5um

    OM2

    OM3

    Max. Attenuation

    dB/km(nm)

    0.4/0.3(1310/1550)

    0.3(1550)

    2.8(850)

    3.0(850)

    2.8(850)

    2.8(850)

    Min. Bandwidth

    MHz km(nm)

    -

    -

    500/500(850/1300)

    200/200(850/1300)

    750(850)

    2000(850)

    Dispersion coefficient

    ps/nm² km

    ≤3.0(1310nm)

    2.6-6.0(1550nm)

    -

    -

    -

    -



    Features of SM G652D Duplex Fiber Optical Cable Assembly


    Single-fiber connector type available in LC, SC with APC or UPC polishing type
    Fiber type available in SM (G652D, G657A1, G657A2), MM (OM3, OM4)
    Pull proof jacket
    Cable length available in 1m, 2m, 3m, etc

    Factory terminated & tested with guaranteed quality

    Jacket material: 0.9mm/2.0mm/3.0mm cable LSZH, OFNR, OFNP

    Applications of MM duplex patchcord

    Telecommunication networks
    Data processing networks

    Links between electronic equipment and fiber patch panels

    Premise installation


    Drawing and cable length tolerance


    Length Tolerance

    L<1M

    ±0.08M

    1M≤L<20M

    ±0.10M

    L≥20M

    ±1%M
